Specifiche tecniche per trattore agricolo Deutz Fahr Agrotron 6.00/6.05/6.15/6.20/6.30/6.45 :
Modello | Deutz Fahr Agrotron 6.00 | Deutz Fahr Agrotron 6.05 | Deutz Fahr Agrotron 6.15 | Deutz Fahr Agrotron 6.20 | Deutz Fahr Agrotron 6.30 | Deutz Fahr Agrotron 6.45 |
Anni di produzione | 95-97 | 95-97 | 95-97 | 95-97 | 95-97 | 95-97 |
Modello / tipo di motore | BF6L1012E | BF6L1012E | BF6L1012E | BF6L1013E | BF6L1013E | BF6L1013E |
Numero di cilindri / turbocompressore | 6T | 6T | 6T | 6T | 6T | 6T |
Cilindrata motore (cm3) | 4788 | 4788 | 4788 | 7146 | 7146 | 7146 |
Dimensione / corsa del pistone (mm) | 94×115 | 94×115 | 94×115 | 108×130 | 108×130 | 108×130 |
Potenza massima del motore (CV) / giri / min | 95/2300 | 105/2300 | 115/2300 | 115/2300 | 132/2300 | 145/2300 |
Coppia (Nm) / rpm | 380/1380 | 415/1380 | 445/1380 | 461/1380 | 520/1380 | 579/1380 |
Numero di marce (anteriore + posteriore) | 24+8 | 24+8 | 24+8 | 24+8 | 24+8 | 24+8 |
Numero di marce sincronizzate (anteriore + posteriore) | 24+8 | 24+8 | 24+8 | 24+8 | 24+8 | 24+8 |
Cambio di velocità | 4 | 4 | 4 | 4 | 4 | 4 |
Tipo di retromarcia | hydr | hydr | hydr | hydr | hydr | hydr |
Velocità di guida (km/h) | 2,8-39,3 | 2,8-39,3 | 2,8-39,3 | 2,8-39,3 | 2,9-41,0 | 2,9-41,0 |
Velocità di guida massima (km / h) | – | – | – | – | – | – |
Capacità della pompa idraulica (L / min) | 83 | 83 | 83 | 83 | 83 | 83 |
Controllo dell’attacco a 3 punti | ehr | ehr | ehr | ehr | ehr | ehr |
Carico massimo attacco a 3 punti (kg) | 6220 | 9240 | 9240 | 9240 | 9240 | 9240 |
Velocità PTO (giri / min) | 540/1000 | 540/1000 | 540/1000 | 540/1000 | 540/1000 | 540/1000 |
Tipo di freno a disco (asciutto / bagnato) | – | – | – | – | – | – |
Tipo di controllo del sistema frenante | hydr | hydr | hydr | hydr | hydr | hydr |
Raggio di sterzata 2WD (m) | – | – | – | – | – | – |
Raggio di sterzata 4WD (m) | 9,9 | 9,9 | 9,9 | 9,9 | 9,9 | 9,9 |
Ruota anteriore 2WD | – | – | – | – | – | – |
Ruota anteriore 4WD | 16,9R24 | 16.9R24 | 16.9R24 | 16.9R24 | 16.9R28 | 16.9R28 |
Ruota posteriore 2WD | – | – | – | – | – | – |
Ruota posteriore 4WD | 18.4R38 | 18.4R38 | 18.4R38 | 18.4R38 | 20,8R38 | 20,8R38 |
Peso totale 2WD (kg) | – | – | – | – | – | – |
Peso totale 4WD (kg) | 5010 | 5010 | 5110 | 5360 | 5360 | 5390 |
Altezza totale con cabina (cm) | 286 | 286 | 286 | 286 | 296 | 296 |
Lunghezza totale (cm) | 452 | 452 | 452 | 468 | 468 | 468 |
Larghezza totale (cm) | 265 | 265 | 265 | 277 | 277 | 277 |
Capacità serbatoio carburante (l) | 260 | 260 | 260 | 260 | 260 | 260 |
Livello sonoro cabina (dB) | 74,5 | 74,5 | 74,5 | 74,5 | 74,5 | 74,5 |
Aggiungi opinione su Deutz Fahr Agrotron 6.00/6.05/6.15/6.20/6.30/6.45:
Controlla anche le scheda tecnica di :
- Deutz Fahr Agrotron 106/110/115/135
- Deutz Fahr Agrotron 108/118/128/120/130/150
- Deutz Fahr Agrotron 130/140/155/165/150.7/165.7/180.7
- Deutz Fahr Agrotron 175/200/205/230/260
- Deutz Fahr Agrotron 210/235/265/215
- Deutz Fahr Agrotron 4.70/4.80/4.85/4.90/4.95
- Deutz Fahr Agrotron 410/420/600/610/615
- Deutz Fahr Agrotron 6120 TTV/6130 TTV/6140 TTV
- Deutz Fahr Agrotron 6120/6130/6140/6150/6160/6180/6190
Il marchio tedesco è nato dalla fusione di due aziende. Deutz, fondata nel 1864, famosa per la produzione di motori a combustione interna, e Fahr (1870), che inizialmente produceva trattori agricoli e più tardi aggiunse alla sua gamma anche le mietitrebbie. La Deutz-Fahr di oggi è una delle aziende che producono una varietà di macchine agricole, compresi i sollevatori telescopici.
