Specifiche tecniche per trattore agricolo John Deere 6120/6220/6320/6420/6420 S:
Annuncio
Modello | John Deere 6120 | John Deere 6220 | John Deere 6320 | John Deere 6420 | John Deere 6420 S |
Anni di produzione | – | – | – | – | – |
Modello / tipo di motore | 4045T | 4045T | 4045T | 4045T | 4045T |
Numero di cilindri / turbocompressore | 4T | 4T | 4TI | 4TI | 4TI |
Cilindrata motore (cm3) | 4530 | 4530 | 4530 | 4530 | 4530 |
Dimensione / corsa del pistone (mm) | 106,5×110 | 106,5×110 | 106,5×110 | 106,5×127 | 106,5×127 |
Potenza massima del motore (CV) / giri / min | 85/2100 | 95/2100 | 108/2100 | 120/2100 | 125/2100 |
Coppia (Nm) / rpm | 331/1495 | 370/1495 | 411/1495 | 438/1495 | 457/1495 |
Numero di marce (anteriore + posteriore) | 24+24 | 24+24 | 24+24 | 24+24 | 24+24 |
Numero di marce sincronizzate (anteriore + posteriore) | 24+24 | 24+24 | 24+24 | 24+24 | 24+24 |
Annuncio
Cambio di velocità | 4 | 4 | 4 | 4 | 4 |
Tipo di retromarcia | hydr | hydr | hydr | hydr | hydr |
Velocità di guida (km/h) | 1,6-40,0 | 1,6-40,0 | 1,6-40,0 | 1,6-40,0 | 1,6-40,0 |
Velocità di guida massima (km / h) | 40 | 40 | 40/50 | 40/50 | 40/50 |
Capacità della pompa idraulica (L / min) | 96 | 96 | 96 | 96 | 96 |
Controllo dell’attacco a 3 punti | ehr | ehr | ehr | ehr | ehr |
Carico massimo attacco a 3 punti (kg) | 4560 | 5100 | 5900 | 5900 | 5900 |
Velocità PTO (giri / min) | 540/1000 | 540/1000 | 540/1000 | 540/1000 | 540/1000 |
Tipo di freno a disco (asciutto / bagnato) | – | – | – | – | – |
Tipo di controllo del sistema frenante | hydr | hydr | hydr | hydr | hydr |
Raggio di sterzata 2WD (m) | – | – | – | – | – |
Raggio di sterzata 4WD (m) | 8,82 | 8,82 | 8,82 | 8,82 | 8,82 |
Annuncio
Ruota anteriore 2WD | – | – | – | – | – |
Ruota anteriore 4WD | 13,6R24 | 420/70R24 | 420/70R24 | 16,9R24 | 16,9R24 |
Ruota posteriore 2WD | – | – | – | – | – |
Ruota posteriore 4WD | 16,9R34 | 480/70R38 | 480/70R38 | 18,4R38 | 18,4R38 |
Peso totale 2WD (kg) | – | – | – | – | – |
Peso totale 4WD (kg) | 4350 | 4390 | 4540 | 4750 | 4750 |
Altezza totale con cabina (cm) | 265 | 271 | 271 | 274 | 274 |
Lunghezza totale (cm) | 429 | 429 | 429 | 429 | 429 |
Larghezza totale (cm) | 240 | 240 | 240 | 240 | 240 |
Capacità serbatoio carburante (l) | 165 | 165 | 185 | 185 | 185 |
Livello sonoro cabina (dB) | 73 | 73 | 75 | 75 | 75 |
